Clevo NJ50PU - External Locator - Left Side & Rear View

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
/
Figure 4
Left Side View
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor
Port
4. USB 3.2 Gen 2
Type-C Port with
DisplayPort and
Power Delivery
5. Vent
6. HDMI-Out Port
7. USB 3.2 Gen 1
Type-A Port
Or
(Factory Option)
Powered USB 3.2
Gen 1 Type-A Port
LEFT SIDE VIEW
1
2
3
4
5
6 7
Figure 5
Rear View
1. Battery
REAR VIEW
1
