Clevo NP50HP - External Locator - Left Side & Rear View

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
/
Figure 4
Left Side View
1. Security Lock Slot
2. Vent
3. USB 3.2 Gen 1
Type-A Ports
4. USB 2.0 Port
5. Microphone-In
Jack
6. 2-In-1 Audio Jack
(Headphone and
Microphone)
7. Speaker
LEFT SIDE VIEW
1
2
3
4
5
6
7
Figure 5
Rear View
1. Vent
2. HDMI-Out Port
3. Mini DisplayPort
1.4
4. DC-In Jack
5. Thunderbolt 4 Port
REAR VIEW
1
1
2
3
5
4
