Clevo NP50HP User Manual

Disassembly
2 - 8 Removing the M.2 SSD Module
2.Disassembly
Removing the M.2 SSD Module
M.2 SSD-1 Removal Procedure
1. Turn off the computer, turn it over, remove the battery (page 2 - 5).
2. The M.2 SSD module will be visible at point on the mainboard. Remove the screw
(Figure 2a).
3. The M.2 SSD module (Figure 2b) will pop-up, and you can remove it from the computer.
4. Reverse the process to install a new module (do not forget to replace the screws and make sure that the thermal
pad is attached).
1
2
3
4
a.
2
3
1
3
4
b.

3.M2 SSD Module
SATA/PCIE
•1 Screw
Figure 2
M.2 SSD-1 Module
Removal
a. Locate the M.2 SSD and
remove the screw.
b. The M.2 SSD module
will pop up.
