Disassembly
2 - 6 Removing the Battery
2.Disassembly
4. The battery will be visible at point on the computer (Figure 2d).
5. Carefully disconnect the cable , then remove screws
- (Figure 2e).
6. Lift the battery off the computer (Figure 2f
).
7. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover).
Figure 2
Battery Removal
(cont’d.)
d. Locate the battery.
e. Disconnect the cable and
remove the screws.
f. Lift the battery off the
computer.
To Next Page
