Clevo PD50PNT User Manual

Introduction
Specifications 1 - 3
1.Introduction
Keyboard
Full Size Multi Full Color LED Keyboard (with numeric key-
pad)
Or
(Factory Option) Full Size Full Color “Per Key” LED Key-
board (with numeric keypad)
Storage
Two M.2 2280 PCIe Gen4 x4 SSDs supporting RAID level 0/
1
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Built-In Array Microphone
Two Speakers
Sound Blaster Atlas
Card Reader
MicroSD Card Reader
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for PCIe Gen4 x4 SSD
Slot 3 for PCIe Gen4 x4 SSD
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
1.0M HD Webcam
Or
(Factory Option) 2.0M FHD Webcam
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wi-Fi 6E AX211, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6E AX210, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6 AX201, 2x2 AX
Wireless LAN + Bluetooth
(Factory Option) Killer™ Dual Band
Wi-Fi 6E AX1675i 2x2 AX Wireless LAN + Bluetooth
(Factory Option) Killer™ Dual Band
Wi-Fi 6E AX1690i 2x2 AX Wireless LAN + Bluetooth
Interface
Two USB 3.2 Gen 1 Type-A Ports (Including one AC/DC
Powered USB Port)
One DisplayPort 1.4 over USB 3.2 Gen 2 Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB3.2).
One Thunderbolt 4 Port**
**The power output of the Thunderbolt 4 port is 5V/3A.
One Mini DisplayPort 1.4
One HDMI-Out Port
One 2-In-1 Audio Jack (Microphone / S/PDIF Optical)
One 2-In-1 Audio Jack (Headphones / Microphone)
One RJ-45 LAN Jack
One DC-In Jack
Features
Virtual Reality Ready
Windows® Mixed Reality Compatible
Pantone Certificate*
NVIDIA G-SYNC Technology at Dynamic Display Switch
mode*
*These features apply to some individual model designs
within this series (check with your distributor/supplier for
details).
Environmental Spec
Temperature
Operating: 5°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Embedded 6 Cell Polymer Battery Pack, 80Wh
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 20V, 11.5A (230W)
Dimensions & Weight
358mm (w) * 240mm (d) * 24.9mm (h)
2.4kg (Barebone with 80Wh Battery)
