Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn off the computer, turn it over.
2. Remove screws
- (Figure 1a).
3. Carefully lift the bottom case
up in the direction of the arrow at point - (Figure 1b).
4. Remove the bottom case .
5. The battery will be visible at point on the computer (Figure 1c
).
1
16
17
18
19
17
20
Figure 1
Battery Removal
a. Remove the screws.
b. Lift the bottom case.
c. Locate the battery.
2
a.
b.
c.
1
17
18
7
8
9
11
12
10
4
5
6
3
20
17
13
14
15
16
19
17. Bottom Case
•16 Screws
