Disassembly
2 - 6 Removing the Battery
2.Disassembly
6. Carefully disconnect the cable , then remove screws - (Figure 2d).
7. Lift the battery off the computer at point as shown (Figure 2e
).
8. Reverse the process to install a new battery (do not forget to replace all the screws and bottom cover).
21
22
24
25
26
Figure 2
Battery Removal
(cont’d.)
d. Disconnect the cable and
remove the screws.
e. Lift the battery off the
computer.
e.
25
21
22
23
25
d.
24
26
25. Battery
•3 Screws
