Clevo W230SD - External Locator - Front View with LCD Panel Open

Introduction
1 - 4 External Locator - Front View with LCD Panel Open
1.Introduction
External Locator - Front View with LCD Panel Open
Figure 1
Top View
1. PC Camera
2. *PC Camera LED
*When the PC
camera is in use, the
LED will be
illuminated in red.
3. Built-In Microphone
4. LCD
5. Power Button
6. LED Indicators
7. Keyboard
8. Touchpad & Buttons
10
2
1
8
6
7
4
5
3
