Clevo W230ST Service Manual

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
Processor Options
Intel® Core™ i7 Processor
i7-4900MQ (2.80GHz)
8MB L3 Cache, 22nm, DDR3L-1600MHz, TDP
47W
i7-4800MQ (2.7GHz), i7-4700MQ (2.4GHz)
6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP
47W
Core Logic
Intel® HM87 Chipset
BIOS
48Mb SPI Flash ROM
AMI BIOS
Memory
Two 204 Pin SO-DIMM Sockets Supporting
DDR3L 1600MHz Memory
Memory Expandable up to 16GB
(The real memory operating frequency depends
on the FSB of the processor.)
Storage
One Changeable 2.5" 9.5mm (h) SATA HDD
(Factory Option) Two mSATA Solid State Drives
(SSD) supporting RAID Level 0/1
LCD
13.3" (33.78cm) HD+ / FHD
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Sound Blaster ™ Cinema
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Keyboard
Illuminated “WinKey” keyboard (with embedded
numeric keypad)
Pointing Device
Built-in Touchpad
Video Adapter
Intel® Integrated GPU and NVIDIA® Discrete
GPU
Supports NVIDIA® Optimus Technology
Intel Integrated GPU
Intel® HD Graphics 4600
Dynamic Frequency (Intel Dynamic Video Mem-
ory Technology for up to 1.7GB)
Microsoft DirectX®11 Compatible
NVIDIA® Discrete GPU
NVIDIA® GeForce 765M
2GB GDDR3 Video RAM on board
Microsoft DirectX® 11.1 Compatible
Interface
One USB 2.0 Port
Three USB 3.0 Ports
(Including one AC/DC
Powered USB 3.0 Port)
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
Mini Card Slots
Slot 1 for WLAN Module or WLAN and Blue-
tooth Combo Module
Slot 2 for mSATA SSD
(Factory Option) Slot 3 for 3G Module or
mSATA SSD
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
Communication
Built-In Gigabit Ethernet LAN
2M HD PC Camera Module
(Factory Option) 3G Mini-Card Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Intel® Wireless-AC 7260 Wire-
less LAN (802.11a/c) + Bluetooth 4.0
(Factory Option) Intel® Wireless-N 7260 Wire-
less LAN (802.11a/g/n) + Bluetooth 4.0
(Factory Option) Intel® Wireless-N 7260 Wire-
less LAN (802.11b/g/n) + Bluetooth 4.0
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n)
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
