Clevo W251ESQ User Manual

Introduction
1 - 4 Specifications
1.Introduction
Audio
High Definition Audio Interface
Built-In Microphone
2 * Built-In Speakers
THX TruStudio Pro
Keyboard, Pointing Device & Buttons
Isolated Keyboard with Numeric Keypad
Built-in Touchpad with Multi-Gesture Functionality
Interface
One USB 2.0 Port
Two USB 3.0 Ports
One eSATA Port
One External Monitor Port
One HDMI1.4a Out Port (with HDCP)
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Card Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC
- MS/ MS Pro/ MS Duo
Note: Some of these cards require PC adapters that are
usually supplied with the cards.
Slots
Two Mini-Card Slots:
Slot 1 for Half Size WLAN Combo Module with PCIe and
USB Interface
Slot 2 for Full Size 3.75G Module with USB Interface
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
Intel ® Centrino ® Advanced-N 6235 (2*2 802.11 a/g/n) Half
Mini-Card PCIe WLAN & Bluetooth 4.0 Combo Module (
Fac-
tory Option
)
Intel ® Centrino ® Wireless-N 2230 (1*2 802.11 b/g/n) Half
Mini-Card PCIe WLAN & Bluetooth 4.0 Combo Module (
Fac-
tory Option
)
Combo WLAN (802.11b/g/n) and Bluetooth v3.0+HS Half
Mini-Card Module with PCIe Interface (Factory Option)
WLAN 802.11b/g/n Half Mini-Card Module with PCIe
Interface (Factory Option)
1.3M/2.0M Pixel PC Camera Module with USB interface
(Factory Option)
==============================
UMTS/HSPDA-based 3.75G Module with USB Half Mini-
Card Interface (
Factory Option )
Quad-band GSM/GPRS (850 MHz, 900 MHz, 1800 MHz,
1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be used in North
America
Power Management
Supports Wake on LAN
Supports Wake on USB
Power
Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 19V, 4.74A (90 Watts)
Removable 6 Cell Smart Lithium Ion Battery Pack 48.84WH
Removable 6 Cell Smart Lithium Ion Battery Pack 62.16WH
(Factory Option)
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Operating System
Windows® 7 with Service Pack 1
Design Feature
Painted Style Covers (For Some Designs Only)
IMR (Injected Molded Resin) LCD Back Covers (For Some
Model Designs)
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
374mm (w) * 25.0mm (d) * 14.3 - 37.2mm (h)
OR (Design Style Dependent)
374mm (w) * 25.0mm (d) * 20 - 37.2mm (h)
2.6 kg with ODD & 48.84WH Battery
