Introduction
Mainboard Overview - Top (Connectors) 1 - 11
1.Introduction
Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. USB Ports
2. Inverter
Connector
3. Speaker
Connector
4. LCD Cable
Connector
5. Power switch
connector
6. Keyboard Cable
Connector
7. Audio Board
Connector
8. Microphone
Cable Connector
9. TouchPad Cable
Connector
8
7
9
1
1
5
2
3
4
6
