Click CPAC1609-H - Performance Parameters; Notice

5
• When cooling, close the curtains. This will
prevent counteracting cooling eect in
summers.
• Use the timer eectively. Set the timer for the
desired operating time.
• To protect the unit, we recommend not
using the cooling function when the ambient
temperature is higher than 35°C.
• Try to create a uniform circulation of room air.
Adjust air flow direction for even circulation of
room air.
• To ensure optimal eciency of the product,
keep doors and windows closed when it is
used as an air conditioner or dehumidifier. If
the product is being used with the fan function
only, an open window could improve air
circulation.
NOTE: For optimum performance, operate
the unit under the usable operating
temperature and humidity conditions
indicated in this owner’s manual. If the
unit operates beyond these conditions,
it may cause malfunctions of the unit or
condensation to drip from the unit.
PERFORMANCE
PARAMETERS
Model CPAC1609-H
Power
AC 220-240V
~ 50Hz
Rated cooling capacity(W)
9000BTU
(2.64KW)
Rated heating capacity (W)
7000BTU
(2.05KW)
Rated input power(W)
Cool 1010W
Heat 810W
Refrigerant/Charge R290/195g
Air flow volume(m³/h) 350
Max. Dehumidifying capacity
(L/h)
1.75
Waterproof class IP20
Protection class Class I
Climate type T
Working temperature 7-35°C
Note: As a result of continual
improvements, the design and
specifications of the product within may
dier slightly to the unit illustrated on the
packaging.
NOTICE:
1. The indicated noise parameter is measured in
laboratories before leaving factory.
2. The rated cooling capacity is tested under the
following conditions:
Cooling
operation
35°C(DB) 24°C(WB)
The rated heating capacity is tested under the
following conditions:
Heating
operation
20°C(DB) 12°C(WB)
3. We will not make formal notice for any
change in parameters. Please take the name
plate attached to the air conditioner as major
reference.
4. Operating temperature range:
Maximum
cooling
Minimum
cooling
DB/WB (°C) 35/24 21/15
5. Wiring diagram of the air conditioner is attached
on the unit.
6. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
7. The air conditioner must be operated within the
temperature range indicated below:
Mode Room temperature
Cool 17-35°C
Dehumidifying 7-35°C
