Plastic stopper
Screw
Shelf
WOODSHELVES (depending models)
1. Place wood shelves on grooves at height desired.
2. Insert metal stoppers (knobs) in the holes (pre-drilled) on both sides of black liner.
The charge capacity of the shelves is about 12 Kg.
REVERSING THE DOOR SWING
Your wine cellar comes equipped with a reversible door. To reverse the door swing, use the extra
set of opposite hinge (inside the wine cellar at time of shipping).
Models 18, 22,40, 44 and 50 botlles.
1 . Using a Phillips head screwdriver unscrew top hinge
and remove. Lift door off bottom hinge post and set
carefully aside. Be careful not to damage locking
mechanism located on bottom of door. Repeat on
bottom on the other side.
2. Remove plastic hole plugs on opposite side of wine
cellar
cabinet.
3. Screw on bottom hinge.
4. Line up hole bottom of wine cellar door with hinge
post on bottom door hinge and set door on hinge post.
5. Line up hole on top of side of wine cellar door with
hinge post on top.
6. Screw on top hinge
7. Replace plastic plugs in screw holes on opposite side
of cabinet.
18
