ControlSchemes
ClimateWizardcoolersaresuppliedfromthefactorywithone(1)WallControlanda20mcontrolcable. Thismakesit
possiblefortheCoolertobecontrolledindependentlyandautomaticallyfromthezonetowhichitisdeliveringcoolair.No
additionalequipmentisrequired. TheWallControlincorporatesathermostatthatregulatesfanspeedtomaintainindoor
temperaturewithin 0.5 Cofthesettemperature.ClimateWizardCoolersarealsosuppliedwithaninterfacetoenable
thecoolertobecontrolledfromanexternallocation,usingaBMSsystem.
Whatevercontroloptionisbeingused,theinbuiltClimateWizardwatermanagementandfaultmonitoringfeaturesare
fullyoperational. TheClimateWizardcontrolschemeincorporatessomeParametersthatcanbealteredtoothersettings
ifthedefaultsettingsarenotsuitable.
IndividualcoolerscanbecontrolledcompletelyfromwithintheircoolingzoneusingtheWallControl-thermostatsupplied.
A 20mconnectingcable,pluggedeachendissupplied.40mcablesarealsoavailableonrequest.-p/n833897.
MaximumpermissiblecablelengthbetweentheWallControlandthecooleris40m.
Nointerconnectionbetweencoolerstoachieve‘Groupcontrol’ ispossible.
ClimateWizardCoolersaresuppliedwithan‘InterfacePCB’.
+
0
Localzonecontrol
BuildingManagementSystem(BMS)Interface
ThiscanbesetuptocontroltheClimateWizardfromEXTERNAL devices,suchasPLCsandBuildingManagement
Systems.InthiscasetheClimateWizardwillceasetofunctioninitsstandard AUTO[Auto]orMANUAL [Man]modeand
willrespondonlytotheexternalcommands.
Fourplugreceptaclesareprovidedintheelectricalcontrolenclosureasshown. Thesearesolelyforthecontrolofthe
coolerfromaremotelocation.
Controlfromremotelocation
