1.8 Power supply
The CVM 2 has a 230 Vac supply to terminals 49 and 50, phase and neutral respectively.
2 Setup
2.1 Access to programming
Press the MENU key;
$ The corresponding LED will light up and two fixed values will be displayed.
+ Press the SET key;
$ The parameter index (on the right-hand side of the display) will start flashing.
+ Scroll through the parameter list using the “arrow up” and “arrow down” keys to visualise the required parameter.
+ Press the SET key
$ the value of the parameter (on the left-hand side of the display) will start flashing.
+ Modify the value using the “arrow up” and “arrow down” keys.
+ Press the SET key to confirm the operation.
+ To access the FACTORY menu scroll through the list until parameter 92 appears, then enter the password.
+ To exit, press the MENU key.
WARNING
To memorise the modifications and make them active you must turn off the power supply (using the main switch)
and, after a few seconds, turn it back on.
