AIR-CONDITIONERS
COMPACT and SPLIT QUATTRO models
page 20
www.climma.it
5.1 - ELECTRICAL BOX
The COMPACT & SPLIT QUATTRO air-conditioners are available in the CO configuration (Cooling Only).
5.2 - SUPPLY
Check that the available supply corresponds to the label on the unit, on the box and on the electrical pump.
A bipolar switch with suitable fuses supplies the connection board of every unit.
The supply cables must be proportionated to the charge. The supply must be connected to the terminal
board, for which section wires up to 4 mm are suitable. Fasten the cable using the suitable clamps.
5 ELECTRICAL CIRCUIT
