AIR-CONDITIONERS
COMPACT and SPLIT QUATTRO models
page 22
www.climma.it
5 - FUNCTIONS OF THE BOARD
5.2 - BOARD SETTING
The board connected to the group has already
been set. Set only replacement material or
when you exchange boards and groups.
Detail of the setting device (detail 2 of the figure 1).
Figure 1
5 EKLECTRICAL CIRCUIT
FUNCTIONS OF THE BOARD / CAPTION
Paragraph Page
1 ADJUSTABLE DELAY 5.1 21
2 BOARD SETTING 5.2 22
3 POWER FUSE 5.3 23
4 FUNCTIONING WARNING LIGHTS 5.4 24
5 SELECTOR FOR MULTIPLE INSTALLATIONS 5.5 25
DIP SWITCH
