AIR-CONDITIONERS
COMPACT and SPLIT QUATTRO models
page 23
www.climma.it
5 - FUNCTIONS OF THE BOARD
5.3 - POWER FUSE
A power fuse is included in the board. For the value, make reference to the value.
Detail of the power fuse and of its ca-
sing (detail 3 of the figure 1).
Figure 1
5 ELECTRICAL CIRCUIT
FUNCTIONS OF THE BOARD / CAPTION
Paragraph Page
1 ADJUSTABLE DELAY 5.1 21
2 BOARD SETTING 5.2 22
3 POWER FUSE 5.3 23
4 FUNCTIONING WARNING LIGHTS 5.4 24
5 SELECTOR FOR MULTIPLE INSTALLATIONS 5.5 25
