AIR-CONDITIONERS
COMPACT and SPLIT QUATTRO models
page 24
www.climma.it
5.4 - FUNCTIONING WARNING LIGHTS
On the board there are some functioning warning lights. The following outline shows their functions.
A
B
C
D
E
F
G
HP LED
LED ON WHEN
POWERBOARD SET
MASTER
ALARM POMP
IN-USE LIGHT
RC - CO
IN-USE LIGHT
COMPRESSOR
IN-USE LIGHT
FAN
POWER ON LED
5 - FUNCTIONS OF THE BOARD
The figure shows the position of the function-
ing warning lights (detail 4 of the figure 1).
Figure 1
5 ELECTRICAL CIRCUIT
FUNCTIONS OF THE BOARD / CAPTION
Paragraph Page
1 ADJUSTABLE DELAY 5.1 21
2 BOARD SETTING 5.2 22
3 POWER FUSE 5.3 23
4 FUNCTIONING WARNING LIGHTS 5.4 24
5 SELECTOR FOR MULTIPLE INSTALLATIONS 5.5 25
