Model FL-20A Cable Fault Locator
Replacement Parts
Note: Printed circuit boards are carefully constructed and calibrated at the factory. Components are not
supplied for eld repair of boards. Please return faulty circuit boards to the factory for repair and calibra-
tion.
Part Number Description
91501P Touchscreen Display Color, Programmed
91526 Power Supply 24V DC 200W
91175 Power Supply 70W
91497C Stepper Motor 4-wire
91549 Timing Belt
91498 Potentiometer 1K 10-Turn 5W
91494 PC Board Assembly High Voltage Bridge
91496 PC Board Assembly Low Voltage Main
91499 Power Supply 20kV 125W
91627C Rotary Solenoid 10v DC w/Connector
02606 Fuse 2 amp 5x20 mm
91610 Transformer 20kV DC 115/230v
91609 Test Lead Assembly 10’
91609-20 Test Lead Assembly 20’
92100
Probe Clip Assembly (for connecting
larger cables)
92113
Probe Clip Assembly (for connecting larg-
est cables)
