9 - TECHNISCHE HINWEISE
MASSZEICHNUNGEN
(1) WASSERE
INTRITT WÄRMETAUS
CHER EUROKONUS 3/4“
(2) WASSERA
USTRITT WÄRMETA
USCHER EUROKONUS 3/4“
(3) KONDENSATA
BLAUFSCHLAUCH Ø 14 MM
Größe
3
5
11
15 17
A
mm 737
937
1137
1337
B
mm
131 131 131 131
C
mm
639 639 639 639
Nettogewicht
kg
17 20 23 26
1537
131
639
29
Ausführung zum Einbau - 4 Rohre
Größe
3
5
11
15 17
A
mm 527
727
927
1127
B
mm
126 126 126 126
C
mm
639 639 639 639
Nettogewicht
kg 9
12
15
18
1327
126
639
21
Sichtbare Ausführung - 4 Rohre
A
B
1
2
3
C
1
2
3
A
B
C
215
214
216
