CLIVET MSAN-XMi 180T User Manual

Contents pag
Installation manual ………………………………………………………………………….. 5
Owner’s manual ……………………………………………………………………………… 19
Certifications ……………………………………………………………………………………. 29
MSAN-XMi 80M - 180T
Size Power supply Reference kW Factory code
80M
230V 1-phase
8 MDV-V80W/DN1
105M
230V 1-phase
10.5 MDV-V105W/DN1
120M
230V 1-phase
12 MDV-V120W/DN1
140M
230V 1-phase
14 MDV-V140W/DN1
160M
230V 1-phase
16 MDV-V160W/DN1(B)
120T
400V+N 3-phase
12 MDV-V120W/DRN1
140T
400V+N 3-phase
14 MDV-V140W/DRN1
160T
400V+N 3-phase
16 MDV-V160W/DRN1
180T
400V+N 3-phase
18 MDV-V180W/DRN1
This manual is for VRF SYSTEM.
To get complete and clear information, please also consider following issues:
1. please consider only 50 Hz electric supply mode
2. Installation Manual, Table 4-3 and Table 4-4:
A = indoor units standard cooling capacity in kW x 10
3. model identification
For 1 outdoor unit connected to 1 indoor unit applications please consider the following instructions.
 Schematics refer to multiple indoor unit design:
for 1 to 1 application please consider the first indoor unit only (first line branch pipe is not needed)
 Installation Manual, Table 4-3 and Table 4-4:
for 1 to 1 application no branch pipe is needed
 Installation Manual, Table 4-8: only for VRF System
for 1 to 1 application please consider 45% ÷ 100% indoor capacity range
 Installation Manual, Chapter 4.6: only for VRF System
 Installation Manual, Table 4-11: only for VRF System
for 1 to 1 application please consider Table 4-10 data
 Owner's Manual, Chapter 1.:
for 1 to 1 application please consider 45% ÷ 100% indoor capacity range
