1.2 Description of system components
1
4
2
3
1 Air outlet
2 Air inlets
3 Refrigerant pipe connector (internal fitting)
4 Fixed stand
l
WARNING
The images in this manual are provided for illustrative purposes only. The appearance of your appliance may
dier slightly from the illustrations shown here. Refer to the actual characteristics of the unit.
Fig. 1
