CLIVET MSAT-XEE 8.2 - Control; Clock Setting and Alarm Silencing; Input;Output Status Display

M09G60E14-04 MSAT-XEE 8.2-30.2 19
7.7 Clock setting
Step Display Action Keys Menu/Variable Notes
1 Main menu Press
Ai
2 Ai Select
CLOCK menu
3 CL Access
Hour
4 Hour Select
Choose
hour: HOUR
date: DATE
year: YEAR
5 YEAR Press 3 sec.
Conrm
! Value ashing !
6 ! 2012 ! Press
Set the value
7 ! 2013 ! Conrm
2013
8 Press
Back to step 4
7.8 Display of inputs - outputs
Step Display Action Keys Menu/Variable Notes
1 Main menu Press
Ai
2 Ai Choose menu
Ai: analogical inputs / digital
di: digital inputs
AO: analogical outputs
dO: digital outputs
3 of Access
diL1
4 diL1 Scroll the list
Choose
diL4
5 diL4 Press to see the value
For digital inputs:
0 = input not active - open
1 = input active - closed
6 Press
Back to the previous menu
For details see:
14.2 Statusp.39
7.9 Silenced alarm
Before resetting an alarm identify and remove its cause.
Repeated resets can cause irreversible damage.
Step Display Action Keys Menu/Variable Notes
1 Er01 The alarm code is ashing
2 13.5°C Alternated to temperature
3
Fixed ALARM led
4 Press any button
5 ALARM led is ashing
For details see:
14.1 Alarmsp.39
