CLIVET MSE-SC 65D User Manual

18 MSE-SC 65D-180F M43X41C6-03
6.6 Connections performer by customer
ALM cumulative fault signal SA1 remote on/o
AP21 remote condenser control module 0..10V SA1.1 second setpoint
AP22 remote condenser control module 0..10V SQ1 utility side exchanger ow switch
FRC1-2 Remote condenser fan thermal overload SQ2.1 owswitch remote exchanger
HL1.....6 compressor status signal SQ2.2 owswitch remote exchanger
KMC1-2 remote condenser on-o control module
KMPU Utility side pump control
6.7 Remote ON-OFF
Do not perform short On O cycles
Do not use the remote On O with thermoregulation function.
A B
A
B
YES NO !
B
A
B
