20 MSE-SC 65D-180F M43X41C6-03
6.9 Communication
AP13 remote interface AP27 Can to Modbus RS485
AP25 Can to Can AP28 Datalogger
AP26 Gateway LonWorks
Cable “A” requirements
Couple of conductors twisted and shielded
Section of conductor 0,22mm2…0,35mm2
Nominal capacity between conductors < 50 pF/m
Nominal impedance 120 Ω
Recommended cable BELDEN 3105A
