Configuration
4.3 DIP Switch settings on main board
SW1_1
[0_]
ON
1 2
Cooling mode temperature compensation:
0°C
[1_]
ON
1 2
Cooling mode temperature compensation:
2°C
SW1_2
[_0]
ON
1 2
Cooling mode temperature compensation:
0°C
[_1]
ON
1 2
Cooling mode temperature compensation:
2°C
SW2
[00]
ON
1 2
Factory settings
SW3_1
[0_]
ON
1 2
Reserved
[1_]
ON
1 2
Indoor unit address deletion
SW3_2
[_0]
ON
1 2
Reserved
SW4
[00]
ON
1 2
When the set temperature is reached
in heating mode, the fan operates on a
4-minute off / 1-minute on cycle.
[01]
ON
1 2
When the set temperature is reached in
heating mode, the fan operates on an
8-minute off / 1-minute on cycle.
[10]
ON
1 2
When the set temperature is reached
in heating mode, the fan operates on a
12-minute off / 1-minute on cycle.
[11]
ON
1 2
When the set temperature is reached
in heating mode, the fan operates on a
16-minute off / 1-minute on cycle.
SW5
[00]
ON
1 2
In heating mode, the fan does not operate
when the temperature midpoint of the
internal heat exchanger is 15°C or lower.
[01]
ON
1 2
In heating mode, the fan does not operate
when the temperature midpoint of the
internal heat exchanger is 20°C or lower.
[10]
ON
1 2
In heating mode, the fan does not operate
when the temperature midpoint of the
internal heat exchanger is 24°C or lower.
[11]
ON
1 2
In heating mode, the fan does not operate
when the temperature midpoint of the
internal heat exchanger is 26°C or lower.
SW6
[00]
ON
1 2
Heating mode temperature compensation:
6°C
[01]
ON
1 2
Heating mode temperature compensation:
2°C
[10]
ON
1 2
Heating mode temperature compensation:
4°C
[11]
ON
1 2
Heating mode temperature compensation:
0°C (use the follow me function)
