Electrical connections
7.4 Location of connections
7.4.1 Sizes 2.1 to 3.1
534
1
2
Fig. 44
1 Hole for high voltage cable (power supply)
2 Hole for low voltage cable (control and signal cables)
3 Hole for drain pipe
4 Water outlet
5 Water inlet
7.4.2 Sizes 4.1 to 8.1
4 3
5
2
1
Fig. 45
1 Hole for high voltage cable (power supply)
2 Hole for low voltage cable (control and signal cables)
3 Hole for drain pipe
4 Water outlet
5 Water inlet
