Dimensional drawings - PREMIUM Version
ELFOEnergy Extended Inverter 21 - 31 - 41
1. Compressor compartment
2. Electrical panel
3. Power input
4. Functional spaces
5. Electric fan (Supply)
6. internal exchanger water inlet (GAS F 1”)
7. internal exchanger water outlet (GAS F 1”)
(M) Air supply
Size 21 31 41
Length mm 942 942 942
Depth mm 433 433 433
Height mm 992 992 992
W1 kg 37 38 40
W2 kg 17 18 20
W3 kg 39 40 42
W4 kg 19 20 22
Operating weight kg 112 116 124
Shipping weight kg 114 118 126
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
DABQ921 REV00
24/11/2014
