M0Q940G14-03 WSAT-XIN 21-171 5
1 Installation quick guide
chapter / page
A On/Standby 6.7 SA1 = On / Standby remotep.22
B SA3: 2° set point 6.6 Connections performer by customerp.20
C Remote alarm signal 6.6 Connections performer by customerp.20
D Remote control 11.1 RCTX - Remote controlp.47
E BUS connection, 100m. 11.1 RCTX - Remote controlp.47
F Power supply 6.4 Power inputp.16
G Water lter 5.7 Water lterp.13
Weight and dimensions 15 Dimensional drawingsp.57
