CLIVET XSC 115D User Manual

39
9 - TECHNICAL INFORMATION
DIMENSIONS: WSH-XSC 85D-90D-100D-110D-115D-120D
1
1
1
1
3
8
8
9
9
8 8
5
6
10
11
W1
W3
W4
W2
11
10
12
13
15
13
14
9 9
1
1
5 - 6
4
2
OD
4 - 7 7
3
OD1
OD2
OD3
18
18
19
19
16
17
1886
39 772 39
850
954
1000
1000
700
1500
800
M N
PO
204 568
488 1317 747
2552
245 360 245
1087 250 146 250
295 76
109
76 295
* 2740
(1) COMPRESSOR
(2) INTERNAL EXCHANGER (EVAPORATOR)
(3) EXTERNAL EXCHANGER (CONDENSER)
(4) INTERNAL EXCHANGER WATER INLET
(5) INTERNAL EXCHANGER WATER OUTLET
(6) EXTERNAL EXCHANGER WATER INLET
(7) EXTERNAL EXCHANGER WATER OUTLET
(8) HOLE TO HANG UNIT
(9) LIFTING BRACKETS
(10) ELECTRICAL PANEL
(11) POWER INPUT
(12) MINIMUM DIMENSION ON THE ELECTRICAL SWITCHBOARD SIDE.
(13) MINIMUM DIMENSION FOR A SAFE PASSAGE.
(14) MINIMUM DIMENSION FOR MAINTENANCE.
(15) MINIMUM DIMENSION FOR WATER CONNECTIONS.
(16) HYDROPACK UTILITY SIDE
(17) HYDROPACK SOURCE SIDE
(18) PUMPS SUCTION
(19) PUMPS SUPPLY
(*) UNIT LENGTH WITH ACCESSORIES CEHU / CEHS "EXCHANGER - HYDRONIC UNIT
CONNECTION SET"
Particular accessories, executions or versions can bring about a great variation of the mass represented here. Please contact our Technical Department.
Size
85D 90D 100D 110D 115D 120D 85D 90D 100D 110D 115D 120D
M mm 1233 1248 1217 1228 1221 1221 1211 1224 1197 1207 1202 1202
N mm 1319 1304 1335 1324 1331 1331 1341 1328 1355 1345 1350 1350
O mm 398 400 399 396 394 394 398 400 399 396 394 394
P mm 452 450 451 454 456 456 452 450 451 454 456 456
OD mm 89 89 89 89 89 89 89 89 89 89 89 89
OD1 mm 89 89 89 89 89 89 89 89 89 89 89 89
Length
mm 2552 2552 2552 2552 2552 2552 2552 2552 2552 2552 2552 2552
Depth
mm 850 850 850 850 850 850 850 850 850 850 850 850
Height
mm 1886 1886 1886 1886 1886 1886 1886 1886 1886 1886 1886 1886
W1
kg 363 357 393 401 409 410 403 397 433 442 449 450
W2
kg 438 448 463 490 492 494 456 466 481 507 510 512
W3
kg 413 403 446 462 475 477 452 442 485 503 515 516
W4
kg 499 507 526 564 572 574 513 519 539 576 585 587
Operating weight
kg 1713 1714 1828 1918 1947 1955 1824 1824 1938 2028 2058 2065
Shipping weight
kg 1659 1660 1761 1851 1875 1891 1770 1770 1871 1961 1986 2001
OD2 mm 89 114 114 114 114 114 89 114 114 114 114 114
OD3 mm 89 114 114 114 114 114 89 114 114 114 114 114
