Cloud CX263 Installation & Setup Guide

10 Technical Specifications
Line Inputs
Microphone Inputs
Outputs
1
1 General Specifications
CX263 Zone Mixer Installation and Setup Guide
CLOUD ELECTRONICS LIMITED
12V2 100904
Power Input 230V/115V ±10%
Fuse Rating
T100mA 230V
T200mA 115V
Fuse Type 20mm x 5mm 250V
Dimensions 482.60mm x 44.00mm(1U) x 152.5mm
Weight(kg) 2.15
Frequency Response 20Hz-22kHz, +0, -0.5dB
Distortion 20Hz-22kHz, <0.05% Typical
Sensitivity 100mV (-17.8dBu) to 1.5V (+6dBu)
Input Gain Control 24dB range
Input Impedance
48kΩ
Headroom >20dB
Noise 20Hz-22kHz (0dB gain), -88dB rms typical
Equalisation LF: ±10dB 50Hz, HF: ±10dB 10kHz
Frequency Response 100Hz -3dB (filter), 20kHz ±0.5dB
Distortion 20Hz-22kHz, <0.05%
Gain Range 10dB to 50dB
Input Impedance
>2kΩ (balanced)
Common Mode Rejection 1kHz, >70dB
Headroom >20dB
Noise 20Hz-22kHz (0dB gain), -128dB EIN
Equalisation LF: ±10dB 150Hz, HF: ±10dB 5kHz
Nominal Output Level 0dBu
Minimum load impedance
1k2Ω
Maximum Output Level +20dBu
