CXV-225 & CXV-425 User Manual v1.012
Technical Specications
CXV-225 & CXV-425
Outputs 100 Vrms; 250 W into 40 Ω min. load (per channel)
Frequency Response 20 kHz -0.6 dB; LF response dependent on lter setting
High Pass Filter -3 dB @ 20 Hz – 200 Hz variable
Distortion <0.04% @ 1 kHz & 1 dB below limiting, 40 Ω load
Crosstalk -80 dB @ 10 kHz
Sensitivity 0.775 Vrms (0 dBu)
Input Impedance 10 kΩ balanced, 5 kΩ unbalanced
Noise (rms) -96 dB, 22Hz - 22kHz, relative to 100 Vrms
Power Input 230 V ±5%
Fuse Rating 230 V, 5 A
Fuse Type T5A, 20 mm x 5 mm 250V
General Specications
CXV-225 CXV-425
Inputs Electronically balanced; 3-pin 2.5 mm-pitch plug-in screw terminal connectors
Outputs 2-pin 5 mm-pitch plug-in screw terminal connectors
Protection Clip Limiting, VI Limiting, DC Offset, Thermal & switch-on delay
Status Indicators LED indicators on each channel for Signal, Peak & Protect
Cooling Force cooled; internal variable speed
DC fan
Force cooled; two rear-mounted
variable speed DC fans
Dimensions
(mm, W x H x D)
482.6 x 88 (2U) x 300 (+ connectors) 482.6 x 132.5 (3U) x 332
(+ connectors)
Weight 8.8 kg net 21 kg net
