3"
"
3) In case of testing with power on, wear rubber gloves to prevent electric shock.
4) When using an instrument or replacing a part for repairing, check it is applied to
rated voltage current and capacity.
5) Prevent water from flowing into electric elements in mechanical parts.
6) When carrying or tilting the appliance, remove all the objects on it.
7) If the cooling cycle is out of order, contact nearest authorized service center for
maintenance, repair and adjustment.
1. SPECIFICATION & PARTS IDENTIFICATION
MODEL
B14A(HOT & COLD)
B14B(COOK & COLD)
DIMENSION
313W×323D×963H(mm)
WEIGHT
16kg
17kg
CONSUMPTION
105W
TEMP CONTROL
AUTO
TANK
Stainless Steel
COLD
CAPACITY
3.0 /h (10)
CONSUMPTION
405W/465W
PROTECTOR
Heat Limiter
TEMP. CONTROL
Hot Control
TANK
Stainless Steel
HOT
CAPACITY
7.5 /h (85)
ELECTRICAL
220-240V, 50/60Hz. 110-127V, 50/60Hz.
Check the available power supply against the watercooler data plate to assure correct electrical service.
