Club Car Precedent Maintenance And Service Manual

ELECTRICVEHICLE-TROUBLESHOOTING
ANDELECTRICALSYSTEMTestProcedures
12
Ifthemeterdoesnotindicatecontinuity,checkandrepairrelatedconnections,Tow/Runswitchandwiring.If
necessary,replaceaffectedwireharness,chargerreceptacleorT ow/Runswitch.
7.Whennished,install15-ampfuseandfusecover.
TESTPROCEDURE11–MCORVoltage
SeeGeneralWarningsonpage1-2.
NOTE:Thisisavoltagetest.
Theacceleratorposition,whichisproportionaltotheMCORvoltage,canbedisplayedwiththeCDThandset.Ifan
CDThandsetisnotavailable,proceedtoMCORVoltageTestwithouttheCDTHandset.
ThefollowingarepotentialMCORsymptoms:
•VehiclewillnotdriveduetonoFOOTINPUTtothecontroller.
•VehiclewillnotreachtopspeedbecauseMCORdoesnotreach100%throttleposition.
•VehicledoesnotmaintainspeednorwillitaccelerateduetoMCORhavinga“dead-spot”initspedaltravel.
•ThevoltagesignalfromtheMCORrandomlyorsporadicallyuctuateswithpedalatrest,duringpedaltraveland
withpedalfullypressed.
MCORVoltageTestwiththeCDTHandset
1.Placechocksatthefrontwheelsandlifttherearofthevehiclewithachainhoistoroorjack.Positionjackstands
undertheframerailsjustforwardofeachspringmount.SeeWARNING“Liftonlyoneend...”inGeneral
Warningsonpage1-2.SeealsofollowingWARNING.
WARNING
•ThekeyswitchshouldbeplacedintheOFFpositionandleftintheOFFpositionfortheduration
ofthistest.
2.ConnecttheCDTtothevehicle.
3.AccesstheMonitormenuandselectTHROTTLE%byusingtheSCROLLDISPLAYbuttons.
4.TheCDTshouldindicate0%withthepedalnotpressed.WhilemonitoringtheCDTdisplayscreen,slowlypress
theacceleratorpedal.Asthepedalispressed,theCDTshouldindicateasteady,incrementalrisefrom0%(pedal
notpressed)to100%(pedalfullypressed).SeefollowingNOTE.
NOTE:Observecloselytoseeifthrottleinputpercentagerandomlyorsporadicallyuctuateswithpedalatrest,during
pedaltravelandwithpedalfullypressed.Ifituctuates,theMCORisdefectiveandmustbereplaced.
5.IftheMCORpassestheprevioustest,pressandholdtheacceleratorpedaltotheoor.Byhand,gentlymove
thepedalfromsidetosideandseeifthethrottleinputpercentageuctuatesfrom100%.Ifituctuates,the
MCORisdefectiveandmustbereplaced.
6.Ifthrottleinputpercentagedoesnotreach100%intheprevioussteps,proceedtoMCORVoltageTestwithout
theCDTHandset.
MCORVoltageTestwithouttheCDTHandset
1.Placechocksatthefrontwheelsandlifttherearofthevehiclewithachainhoistoroorjack.Positionjackstands
undertheframerailsjustforwardofeachspringmount.SeeWARNING“Liftonlyoneend...”inGeneral
Warningsonpage1-2.SeealsofollowingWARNING.
2020Precedent,Villager2and4MaintenanceandServiceManualPage12-23

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
