Club Car Precedent Maintenance And Service Manual

12
TestProcedures
ELECTRICVEHICLE-TROUBLESHOOTING
ANDELECTRICALSYSTEM
4.1.WithTow/RunswitchintheRUNpositionandusingamultimetersetto20voltsDC,placetheblack(–)
probeonthebatteryno.6(6x8-Voltbatteryset)negativepostandplacered(+)probeonredwireterminal
socketinthree-pinconnector.Thevoltagereadingshouldbeapproximately15to16volts.
4.2.Ifthevoltagereadingiszerovolts,checkthecontinuityoftheredwirefromthe16-pinconnectoratthe
speedcontrollertothethree-pinconnectoratthemotorspeedsensor.Ifthewirecontinuityiscorrect,
replacethespeedcontroller.
4.3.Ifthereadingisbelow14volts,replacethespeedcontroller.
4.4.Ifthevoltagereadingiscorrect,proceedtothefollowingstep.
5.Checkvoltageatthelightgreenwire:
5.1.Usingamultimetersetto20voltsDC,placetheblack(–)probeonthebatteryno.6(6x8-Voltbatteryset)
negativepostandplacethered(+)probeonthelightgreenwirefemaleterminalinthethree-pinconnector
atthemotorspeedsensor.Thevoltagereadingshouldbefrom4.60to4.90volts.
5.2.Ifthevoltageiszerovolts,checkthecontinuityofthelightgreenwirefromthe16-pinconnectoratthe
speedcontrollertothethree-pinconnectoratthemotorspeedsensor.Ifthecontinuityiscorrect,replace
thespeedcontroller.
5.3.Ifreadingisbelow3.50volts,checkthecontinuityofthewiresandplugandreplacethespeedcontrollerif
necessary.
6.Reconnectthethree-pinconnectoratthemotorspeedsensor.Usingamultimetersetto20voltsDC,placethe
black(–)probeonthebatteryno.6(6x8-Voltbatteryset)negativepostandplacethered(+)probe(with
insulation-piercingprobe)onthegreenwirebetweenthethree-pinconnectorandthemotorspeedsensor.
6.1.Raiseonerearwheeloffground.Slowlyturntherearwheeltorotatethemotorarmature.Asthearmature
rotates,thevoltagereadingshouldalternatefromzerotoapproximately4.85volts.Thevoltagereadingwill
uctuatefromzeroto4.85voltsandbacktozerofourtimesforeachrevolutionofthemotorarmature.
NOTE:Thevoltagereadingof4.85isanapproximatereading.Theactualreadingmayvaryfrom4.50to5.00volts.
6.2.Replacethespeedsensorifanyofthefollowingresultsoccur:
–Thereisnovoltagereading.
–Thevoltagereadingisnotabove3.50.
–Thevoltagereadingdoesnotuctuateasthemotoristurned.
TESTPROCEDURE13–A1andA2MotorVoltage
SeeGeneralWarningsonpage1-2.
NOTE:Thisisavoltagetest.
1.Placechocksatthefrontwheelsandlifttherearofthevehiclewithachainhoistoroorjack.Positionjackstands
undertheframerailsjustforwardofeachspringmount.SeeWARNING“Liftonlyoneend...”inGeneral
Warningsonpage1-2.SeealsofollowingWARNING.
WARNING
•Keeppeopleandequipmentclearfromrotatingrearwheels.Donotallowpersonsunderthecar.
Contactwithrotatingrearwheelscouldresultinseriouspersonalinjury.
2.Withthebatteriesconnectedandusingamultimetersetto200voltsDC,placetheblack(–)probeontheA2
motorterminal(whitewire)andconnectthered(+)probetotheA1(greenwire)motorterminal.
3.WithTow/RunswitchintheRUNposition,placetheForward/ReverseswitchintheFORWARDposition,turnkey
switchtotheONpositionandslowlypressacceleratorpedal.
Page12-262020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
