PARTS LIST, continued
Key
No.
Part Name
NUMBER REQUIRED PART NUMBERS
Models WB,
WE, WF, WH
Models WJ,
WL WR
Model
WB
Model
WE
Model
WF
Model
WH
Model
WJ
Model
WL
Model
WR
624-140
Motor Attaching Screw and
Lockwasher
--- 4 ----
For all Units, order (4) 87377
Motor Thru Bolts and (4) 982226
Lockwashers
624-142 Loose End Nut 1 1 82638 82639
624-143 Contactor/Capacitor Bracket with
Attaching Screws
--- 1 Order (1) Bracket 24200 and (1) Screw
982688
Order Bracket 35701 and (2)
Screws 983643
624-145 Capacitor Clamp with Attaching
Screws and LockWasher
--- 1 --- Order (1) 35268 Clamp, (1)
982210 Washer, (1) 983544
Lockwasher and (1) 987354 Screw
624-146 Loose End Link 1 1 35367 35367
624-147 Contact Block --- 1 --- --- --- 36764
624-149 Brake Disc Retainer Ring --- 1 --- --- 24801 ---
624-151 Lower Hook with Latch
(Includes Item 624-152)
1 1 28686 28687 28686 28687 35611 35611 35612
624-152 Latch Kit 1 1 45661 45662 45661 45662 45662 45662 45663
624-156 Load Chain (Specify Length) 1 1 85889 (Specify Length Required) 85979 (Specify Length Required)
624-157 Lower Hook Assembly-Complete
(Items 624-151 and 624-158)
1 1 --- 28665 --- 28665 --- --- 35645
624-158 Lower Hook Collar (or Nut) Pin
and Thrust Bearing
1 1 --- C325 --- C325 --- --- C326
624-159 Lower Sheave 1 1 --- 27017 --- 27017 --- --- 35010
624-160 Lower Sheave Bearing 2 2 --- 88429 --- 88429 --- --- 83674
624-161 Hook Block (*Must order in pairs
with 624-162)
2 2 --- 27048 --- 27048 --- --- 35034
624-162 Chain Stop Block 2 23465903C 23465603C
624-163 Chain Stop Screw 2 982517
624-164 Chain Stop Lockwasher 2 10095701
624-165 Chain Stop Nut 2 982514
624-166 Stop Block 1 1 24785 24786
624-167 Alignment Pin 4 2 82354 82354
624-170 Suspension Adapter 1 1 27703 27013 27703 27013 35740 35740 35741
624-171 Upper Hook with Latch
(Includes Item 624-152)
1 1 28689 28697 28689 28697 35617 35617 35616
624-172 Upper Hook Collar (or Nut) and Pin 1 1 C329 C330 C329 C330 C331 C331 C332
624-173 Suspension Adapter Screw 2 2 987554 36849
624-174 Rigid Hook Suspension-Complete 1 1 2788 2789 2788 2789 3651 3651 3658
624-175 Dead End Bolt 1 1 --- 89508 --- 89508 --- --- 35957
624-176 Dead End Block, Pin, Washer
and Cotter Pin
1 1 --- C334 --- C334 --- --- C335
624-177 Suspension Lug 1 1 27450 27452 27450 27452 35456 35456 35457
624-178 Lug Suspension - Complete 2778 2779 2778 2779 3677 3677 3668
624-179 Suspension Adapter Anchor --- 2 --- 35066
624-180 Back Frame Dowel --- 2 --- 35768
624-190 Brake Plate 1 1 24741 24740
624-191 Brake Friction Plate 2 2 24603 24602
624-192 Brake Field 1 1 24606 24608
624-193 Brake Armature 1 1 24607 24609
624-194 Brake Spring 2 2 24731 24732
624-195 Brake Nut 2 2 982442 982443
624-196 Brake Coil Retainer Strap 1 1 24738 24738
624-197 Brake Disc 1 (Models WB, WE)
2 (Models WF, WH, WJ, WL,WR)
27817 24735
624-198 Brake Friction Plate-Double
(Not Required for Models WB, WE)
1 1 24600 24601
624-199 Brake Coil 1 1 See Parts List on Page 22 See Parts List on Page 22
