CM Valustar 2401 - Parts List and Exploded Views

19
KEY
NO.
PART NAME
NUMBER REQUIRED PART NUMBERS
Models WB,
WE, WF, WH
Models WJ,
WL, WR
Model
WB
Model
WE
Model
WF
Model
WH
Model
WJ
Model
WL
Model
WR
624-100 Motor Housing 1 1 27028 24008
624-101 Gear Housing 1 1
28669
(Includes Item 624-102)
35620
(Includes Items 624-102, 624-120, 624-129)
624-102
Intermediate Gear and Pinion
Bearing - Inboard
(Includes Shaft Adapter for WJ, WL, WR)
1 1 88440
Order 83670 (Bearing)
and 24350 (Shaft Adapter)
624-103 Chain Guide 2 2 27008 35018
624-104 Liftwheel 1 1 27360 35421
624-105 Suspension Adapter Nut 2 2 927755 935791
624-106
Motor Housing Cover Screw
and Lockwasher
2 2 C302 C303
624-107 Liftwheel Gear Retainer Ring 1 --- 27767 ---
624-108
Motor Shaft Bearing, Inboard
Retainer Ring
2 2 27790 35764
624-109
Gear Housing Attaching Screw
and Lockwasher
4 4
Order 28830 Screw
and 940802 Lockwasher
Order 982682 Screw
and 940830 Lockwasher
624-110
Loose End Screw, Washer
and Lockwasher
1 1 C304 C305
624-111 Motor Shaft Bearing - Outboard 1 --- 82009 ---
624-112 Motor Shaft Bearing - Inboard 1 1 82003 82004
624-113 Stator Pin 1 --- 983541 ---
624-114
Control Cable Screw, Washer
and Lockwasher
1 1 C306 C306
624-115
Back Frame Assembly
(Includes Brake Studs)
1 1
24620
(Includes 624-116 thru 624-118, 624-127, 624-128)
24622
624-116 Drive Shaft and Pinion Bearing 1 1 82009 83691
624-117
Intermediate Gear and Pinion
Bearing - Outboard
1 1 82009 88437
624-118
Bearing Retainer Screw
and Washers
1 2 C307 C308
624-119
Back Frame Attaching Screw
and Lockwasher
3 4
Order 982699 Screw
and 940802 Lockwasher
Order 982682 Screw
and 940830 Lockwasher
624-120 Liftwheel Bearing - Gear End 1 1 88429 82002
624-121 Motor Housing Cover 1 1 24504 24759
624-122 Back Frame Cover 1 1 24757 24758
624-123
Back Frame Cover Attaching Screw
and Lockwasher
2 2 C309 C310
624-125 Hoist I.D. Label 115-1-60, 230/460 1 1 Contact Factory Contact Factory
624-126 Capacity/Warning Label 1 1 24764 24765 24765 24766 24765 24766 24768
624-127 Hole Plug Set 4 1 982454 C311
624-128 Back Frame Expansion Plug 1 --- 940837 ---
624-129 Gear Housing Plug --- 1 --- 935767
624-130
Drive Shaft and Pinion Assembly
(Includes Items 624-131 thru 624-133 for
Models WB, WE, WF, WH, WJ, WL and WR.
Also Includes Item 624-116 with Models
WJ, WL, WR
1 1
Order 624-116, 624-131,
624-132 and 624-133
24639 24638 24638
624-131 Drive Shaft and Pinion Assembly 1 1
24641
(8T. Pinion, 5-15/64” Long)
24642
(8T Pinion, 5 43/64” Long)
35357
(18T.)
35356
(12T.)
35356
(12T.)
624-132 Brake Hub 1 1
27851
(8T. 21/32” Long)
27852
(8T. 1-1/8” Long)
---
24019
(13T.)
24019
(13T.)
624-133 Brake Hub Retainer Ring 1 1 27766 35766
624-134 Liftwheel Gear 1 1 27009 (53T.) 35009 (79T.)
624-135 Intermediate Pinion 1 1 24351 (8T.) 35351 (10T.)
624-136 Intermediate Gear Retainer Ring 1 1 27765 35763
624-137 Protector 1 1 28694 28695 36668 36670 36670
624-138 Liftwheel Bearing - Motor End 1 1 88429 83669
624-139 Liftwheel Gear Nut and Lockwasher --- 1 --- C312
PARTS LIST
