25
Key No. Part Name No. Req’d. Part No.
1-Ton 2-Ton 1-Ton 2-Ton
624-400 Trackwheel 4435774 50762
624-401 Trackwheel Stud 44987790 35838
624-402 Trackwheel Stud Nut 44982520 948804
624-403 Suspension Bolt
(
Special Alloy Steel Bolt)
9-5/32" long* 2–35450 –
10-1/4" long** 2–35407 –
10" long
†
–2 –35445
12-1/16" long
††
–2 –35414
624-404 Trolley Spacer Washers
0.165" thick* 40 – 35782 –
0.125" thick** 38 – 958822 –
0.165" thick
†
– 32 – 35783
0.125" thick
††
– 38 – 988039
624-405 Suspension Bolt Nut 44948803 958818
624-406 Suspension Bolt Nut Cotter Pin 44988343 988368
624-407 Side Frame, Plain Side
Without Trolley Guards*** 2235640 35654
Trolley Guards*** 2235635 35636
624-408 Side Frame, ID Plate Side
Without Trolley Guards*** 2235640 35654
Trolley Guards*** 2235635 35636
624-409 Load Bracket
3-7/16" wide* 1135019 –
5-13/32" wide** 1135024 –
4-3/16" wide
†
11 –35033
6-11/16" wide
††
11 –35043
624-410 Vertical Load Bar Pin
(
Special Alloy Steel Pin)
2-11/16" long* 1135371 –
2-7/8" long** 11 –35413
3-3/4" long
†
11 –35400
624-411 Vertical Load Bar Pin Screw
1/2" long* 11982383 –
1-1/4" long** 11982386 –
3/4" long
†
11 –982433
1-1/2" long
††
11 –987209
624-412
Vertical Load Bar Pin Screw L.W.
11983548 983547
624-413 Trackwheel Stud Nut L.W. 44987923 987924
624-414 Identification Label 1136916 36917
624-416 Trackwheel Washer –1 –987903
624-417 Warning Label 11936984 936984
Figure 18. Series 635 Low Headroom Trolley Exploded View
Key No. Part Name No. Req’d. Part No.
1-Ton 2-Ton 1-Ton 2-Ton
* These items are for the 1-Ton Trolley for operation on 2.66" thru 5.64"
flange widths.
** These items are for the 1-Ton Trolley for operation on over 5.64" thru 7.00"
flange widths.
*** If side frame is equipped with spacer block, contact factory.
†
These items are for the 2-Ton Trolley for operation on 3.33" thru 6.00"
flange widths.
††
These items are for the 2-Ton Trolley for operation on over 6.00" thru 8.25"
flange widths.
SERIES 635 LOW HEADROOM TROLLEY PARTS LIST
