CMA Dishmachines CMA-44H

Other manuals for CMA Dishmachines CMA-44H

Parts Manual26 pages

Specifications2 pages

Quick Setup Instructions2 pages

Questions and Answers

D
Daniel BentonAug 16, 2025
Why is my CMA Dishmachines CMA-44H Dishwasher machine inoperative?
- N
  Nathaniel CarsonAug 16, 2025
  Several factors can cause your CMA Dishmachines Dishwasher to be inoperative: * A burned-out fuse: Replace the fuse. * Table limit switch: Remove the dish rack at the switch. * Defective door reed switch: Replace the reed switch. * Defective start reed switch: Replace the reed switch. * Defective auto/manual switch: Replace the switch. * Defective 60 Sec. Timer: Replace the timer.
C
Corey ByrdAug 18, 2025
What to do if my CMA Dishmachines Dishwasher has low wash tank temperature?
- A
  amanda36Aug 19, 2025
  If your CMA Dishmachines Dishwasher has a low wash tank temperature, consider the following: * Check the hot water supply, ensuring it is at the correct temperature (150°F for low temp, 180°F for high temp). * Adjust the thermostat setting. * Close vent hoods as much as possible. * If the heater is defective, replace it.
A
Amy SmithAug 21, 2025
How to fix low rinse water pressure or no rinse in my CMA Dishmachines CMA-44H?
- R
  Ronald LongAug 21, 2025
  To address low rinse water pressure or no rinse in your CMA Dishmachines Dishwasher, check these: * Plugged rinse jets: Remove and clean them. * Pressure regulator: Adjust the pressure regulator. * Water solenoid valve coil or diaphragm: Replace or clean. * Dirty rinse jets: Remove and clean the jets. * Defective rinse reed switch: Replace the reed switch.
M
marie95Aug 25, 2025
Why does my CMA Dishmachines CMA-44H Dishwasher machine run continuously?
- C
  Christopher ChenAug 25, 2025
  If your CMA Dishmachines Dishwasher runs continuously, the cause may be a defective 60 Sec. Timer or its settings; in this case, replace the timer or change the settings. Alternatively, the contactor might be stuck, requiring replacement.
S
Spencer WellsAug 27, 2025
What to do if my CMA Dishmachines Dishwasher heater has no heat?
- J
  Jose MontgomeryAug 27, 2025
  If your CMA Dishmachines Dishwasher heater isn't producing heat, consider these potential causes: * Float switch: Check movement and replace if defective. * Defective thermostat or setting: Replace the thermostat or adjust the setting. * Defective heater contactor: Replace the heater contactor. * Defective heater: Replace the heater. * Defective heater switch: Replace the switch. * Wire connections: Check and correct any issues.
R
Rachel BrowningAug 30, 2025
How to resolve low spray arm pressure in CMA Dishmachines Dishwasher?
- K
  Kathleen MartinezAug 30, 2025
  To resolve low spray arm pressure in your CMA Dishmachines Dishwasher: * Check the tank water level, rinse pressure, and ensure the drain valve is closed. * Clean any clogged jets. * Ensure motors are correctly connected to reverse impeller direction.
M
margaret59Sep 2, 2025
What causes racks to get stuck in my CMA Dishmachines Dishwasher?
- S
  Sean BradySep 3, 2025
  Racks can get stuck in your CMA Dishmachines Dishwasher due to a broken rack, which requires replacement, or tray track misalignment, which should be adjusted properly.
J
Jennifer RichardsonSep 5, 2025
What to do about chemicals issue in CMA Dishmachines CMA-44H Dishwasher?
- E
  Elizabeth FergusonSep 5, 2025
  For chemical-related issues with your CMA Dishmachines Dishwasher, check the dispenser troubleshooting guide for dispenser or setting problems and ensure the rinse pressure is set to 20 psi.
H
Heidi BurtonSep 8, 2025
How to solve pre-wash/power wash motor inoperative in CMA Dishmachines Dishwasher?
- M
  Mr. Charles MyersSep 8, 2025
  If the pre-wash/power wash motor is inoperative in your CMA Dishmachines Dishwasher, it could be due to a bad motor or capacitor, in which case you should replace the defective motor. It might also be caused by a faulty contactor; replace the contactor in this case.
A
Anthony WoodsSep 12, 2025
Why is my CMA Dishmachines CMA-44H Dishwasher machine loosing water?
- N
  Natasha MortonSep 12, 2025
  Your CMA Dishmachines Dishwasher might be losing water due to a quick drain on the pre-wash end; plumb the quick drain back into the pre-wash tank above the water line. Alternatively, using sheet pans not designed for the unit can cause water loss, so use a CMA sheet pan rack. Also, ensure the drain valves are completely closed.

Summary

Specifications

CMA-44 Specifications

Detailed specifications for the CMA-44 model, including water consumption, speed, temperature, and dimensions.

Getting Started

Introduction to CMA-44

Overview of the CMA-44's cleaning capabilities, energy efficiency, and design features.

Receiving and Installation

Guidance on unpacking and initial setup, including installing scrap tray and curtains for new models.

Receiving and Installation (Old Models)

Instructions for installing older CMA-44 models, focusing on curtain placement and assembly.

Safety Tips for CMA-44

Essential safety precautions and warnings for operating the CMA-44 dishmachine, covering electrical and mechanical hazards.

Operation

Initial Setup

Procedures for initial setup, including auto-fill timers and rinse pressure regulation.

Beginning Operation

Steps for starting the dishmachine, including filling, heating, and rack placement.

Service and Maintenance Checklist

A comprehensive checklist for routine service and maintenance tasks to ensure optimal performance.

Quick Service Guide

A troubleshooting guide for common technical issues, listing problems, causes, and solutions.

Troubleshooting

Detailed problem-solving guide for diagnosing and fixing operational issues with likely causes and solutions.

Customer Notice

Installation Instructions for New Conveyor Styles

Specific installation guidance for new style CMA-44 and CMA-66 conveyors, emphasizing soil purging and leveling.

Electrical Diagram

CMA-44 Wire Diagram (230 V Three-Phase)

Detailed wiring diagram for the CMA-44 (230V three-phase) with auto re-fill function.

Electrical Diagram (Old Models)

CMA-44 Wire Diagram (Old Models)

Wiring diagram for older models of the CMA-44 (230V three-phase) dishwashers.

CMA Dishmachines CMA-44H Specifications

General

Manufacturer	CMA Dishmachines
Model	CMA-44H
Type	Undercounter Dishwasher
Rack Size	20" x 20"
Amperage	20A
Booster Heater	Optional
Construction	Stainless Steel
Water Consumption	0.74 gallons per rack
Electrical	208-240V/60Hz
Water Temperature	140°F
