TECHNICAL SPECIFICATIONS // PERFORMANCE
Maximum working height ........................................83'
Maximum side reach at 507 lbs, unrestricted .......................46'
Maximum weight load with standard basket ........................507lbs
Maximum weight load with optional single man fiberglass basket .....537lbs
Moveable Jib articulting range ....................................135°
Turret rotation range ............................................+/-400°
Basket rotation range ............................................+/-90°
P Maximum slope to stabilize (deployment) ..........................19° (34%)
Height / Width tracks adjustment .................................7"
W Maximum slope approach angle / slope ............................14° (25%)
X Gradeability -- max. travel angle / slope* ...........................19° (34%)
Gradeability -- max. travel cross hill ...............................19° (34%)
Maximum crawler travel speed** ..................................3 mph
*This s the standard setting. The standard setting can be overridden to: 31° (60.1%)
**3 speeds: Slow, Slow with Torque, Fast
Have questions? Get in touch with us at:
83 HD
+
ARBOR PRO
Maximum Slope Approach Angel 25%
