1B. SPECIFICATIONS
Power Requirements:
• 110V/ 240V
• 60 Hz / 50 Hz
• AOP 25: 0.7 Amps, AOP 40: 1.1 Amps
Weights:
• Shipping Weight: 55lbs/25kg
• Dry Weight: 50lbs/23kg
• Wet Weight: 64lbs/29kg
Location Requirements:
• Mounting: Ground or Wall mounted
• Ambient Recommended Temperature: 30°F - 120°F (0°C - 50°C)
•
CAUTION
Water Level: Additional system back pressure created in certain applications or by certain accessories may
impact the system’s ability to pull vacuum properly. (Example: equipment below water level, in-oor cleaning system, spa
mode, etc) This can result in water pushing back into the ozone gas line and possibly into the ozone cell(s). Please consult
CMP if conditions exist that may introduce higher than normal back pressures (>3 psi).
Recommended Flow Rates
SYSTEM
MIN FLOW NSF TESTED MAX FLOW
AOP 25 - 53000-025-000 10 GPM 30 GPM
AOP 40 - 53000-025-000 20 GPM 40 GPM
• The unit must meet the minimum ow rate to activate the internal ow switch. Below this ow rate the system will not
turn on.
• The NSF Tested max ow is the rate at which a 3-log disinfection rate is achieved to meet the supplemental sanitizer
requirements.
• Operation above the NSF Tested max ow the level of undissolved ozone in the system may increase. A Mixing De-gas
Vessel can be installed after the AOP system to remove excess ozone from the system.
NSF Testing
This product is designed for supplemental disinfection when operated according to these instructions, and should be used
with registered or approved disinfection chemicals to impart residual concentrations. NSF/ANSI 50, Section 13 disinfection
ecacy testing for 3-log (99.9%) or greater of Pseudomonas, Aeruginosa and Enterococcus Faecium. Specic residual levels of
EPA registered disinfection chemicals may be required by the regulatory agency having authority.
1. SYSTEM INFORMATION
