035: Y-bearing*1 pc
017:M5-10*2 pcs screw
019:T nut*2 pcs
Note: Place the center of the profile
026:Coupling*1 pc
021Copper nut*1 pair
Spring*1
024:Nut seat*1 pc
009:Lead screw320mm*1 pc
2
3
4
4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CNC 3018 and is the answer not in the manual?

CNC 3018 Specifications

General IconGeneral
ModelCNC 3018
Work Area300 x 180 x 45mm
ConnectivityUSB
CategoryCNC Router
Frame MaterialAluminum
Spindle Motor775 Spindle Motor (12-36V) 24V: 10000r/min
Power Supply24V 5.6A
SoftwareGRBL
Supported OSWindows
Supported MaterialsWood, Plastic, Acrylic, PCB
