Page #9 background imageLoading...
Page #9 background image
033: Motor mounting plate*1pc
010: Stepper Motor*1 pc
015:M3-6*4pcs Screw
5
019：T nut*2 pc
017: M5-10*2 pcs screw
027：M5 Gasket*2 pcs
5

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CNC 3018 and is the answer not in the manual?

CNC 3018 Specifications

General IconGeneral
ModelCNC 3018
Work Area300 x 180 x 45mm
ConnectivityUSB
CategoryCNC Router
Frame MaterialAluminum
Spindle Motor775 Spindle Motor (12-36V) 24V: 10000r/min
Power Supply24V 5.6A
SoftwareGRBL
Supported OSWindows
Supported MaterialsWood, Plastic, Acrylic, PCB
