6
ENGLISH
6
1
2
3
4
5 7
8
9
10
11
Technical specifications
Voltage 230 V ~ 50 Hz
Power 600 W
No-load speed 500-3000 rpm
Max. sawing depth in wood 65 mm
Max sawing depth in metal 6 mm
Lpa (sound pressure) 90.4 dB (A)
Lwa (sound power) 101.4 dB (A)
Vibration rate 3.3 m/s²
Product description
1. Power switch
2. Locking button
3. Wheel for setting rpm’s
4. Saw blade cover
5. Blade holder
6. Footplate
7. Lever for adjustment
of pendulum movements
8. Holder and Allen key
9. Connection for vacuum adapter
10. Vacuum adapter
11. Saw blade
Accessories
• Allen key
• Saw blades
• Read the entire operations manual.
• Always use ear plugs.
• Always use protective goggles.
Product labelling with safety symbols
