Assembly and adjustment
Important!
Unplug the cord before all types of servicing.
Replacement of saw lades
• Loosen the Allen head
screws (11) holding the
saw blade in place.
• Insert the saw blade into
the groove (5).
• Tighten the screws (11).
• Check that the blade is
correctly installed.
Adjusting the footplate
• The footplate (6) can
be tilted up to 45° to
the right or left.
• Loosen the Allen head
screws (13).
• Adjust to the
desired angle.
• Tighten the screws (13).
