8
ENGLISH
15
14
6
1
2
3
Sawing with parallel stops
• Insert the parallel stop (14)
into the slots.
• Adjust to the desired
measurement.
• Tighten the screws (15).
Turning on/off
Start: Press the power switch (1).
Off: Release the switch.
• To lock the power switch in the
set position, press the locking
button (2) and the power switch
(1) (at the same time).
• To release the lock, press the
power switch and then release.
Adjusting the speed setting
Set the speed by rotating the wheel (3). This can be done also while running. After
sawing for an extended period of time at a low speed setting, the motor should be
allowed to run at maximum for about 3 minutes to cool down the motor.
Adjusting the pendulum
The saw can be adapted to different materials by adjusting the pendulum move-
ment. When the saw blade moves outwards, it is also lifted from the workpiece,
which improves the dust extraction and the cooling of the workpiece.
0. Plate, steel, or rubber.
1. Non-ferrous metals, hardwood, plastics.
2. Wood.
