8a. Place the helper foot opposite the demount
head and push the bead into drop center (figure 36A).
Figure 36A - Helper Foot Pushing Bead Into Drop Center
9. Rotate lifting tool down over wheel to lift bead up
and over the knob and at the same time remove helper
foot (figure 37).
Figure 37 - Rotate Lifting Tool Down for Demount
10. Hold lifting tool in place, depress the table top
rotation pedal momentarily to jog the wheel a short dis-
tance. Check the wheel and tire to verify that operation
is not causing damage. The lifting tool can usually be
removed after jogging the wheel a short distance.
Continue to jog the wheel to allow the tire sidewall to
flex as it crosses the rim edge. Continue short rotations
until top bead is completely demounted (figure 38).
Figure 38 - Rotate Lifting Tool Down for Demount
11. Demount lower bead. In most cases when
demounting performance tires, the lower bead will be
less difficult. Pay close attention to sensor/transmitter
location, and position it just before the demount tool
when starting the lower bead demount procedure (fig-
ure 39).
Figure 39 - Rotate Lifting Tool Down for Demount
12. Use the upper side of the helper foot to hold the
bead in drop center while lifting the lower bead over
the demount tool (figure 40). Hold the lifting tool in
place and remove the helper foot. Depress the table
top rotation pedal momentarily to jog the wheel short
distances to complete the demounting process.
Figure 40 - Helper Holding the Lower Bead in Drop Center
18 • Important: Always read and follow the operating instructions.
