Important:Always read and follow the on-screen operating instructions. • 13
VViiddeeoo BBaallaanncceerr
Special Functions
Press the key and select the SPECIAL FUNC-
TIONS option for the following menu selections.
Figure 20 - Special Functions Screen
Customize the machine by following the on-screen
instructions for functions and/or .
Owner Address -This information appears on the
screensaver. It consists of three lines, each a
maximum of 30 characters.
Operators Name -
Enter up to four different
machine user names, each a maximum of 15
characters.
Follow the on-screen instructions to
complete the customization.
Figure 21 - Operator Name Entry Screen
Machine Self-Test -
Provides software version,
technical, and other machine diagnostic informa-
tion. See DIAGNOSTIC PROCEDURES on page 28.
Static Unbalance Displayed -
Toggles the display of
the Static-on-Screen™ value ON or OFF.
Set to ON.
Stop On Top -
Toggle ON or OFF to automatically
stop the wheel near TDC (top-dead-center) for
outer weight placement.
Set to OFF.
Machine Self-calibration - calibrates the weight
amount and placement.
See MACHINE SELF-CALI-
BRATION AND SERVICE ADJUSTMENTS on page
22 for more information.
Important: Always verify the wheel dimensions
carefully before proceeding with the Machine Self-
calibration.
Additional Functions
Press the key and select the CYCLE HISTORY
option for the following menu.
Figure 22 - Cycle History Screen
Cycle History -
Select
option to set the
number of spins between calibrations (500 - 5000
@ 500 spin increments).
Also, the operator can view the following information
when the CYCLE HISTORY option is selected.
•The number of daily spins that is automatically reset
after switching the machine off.
• View the number of spins since calibration.
• View the total number of spins.
3
13
3
MENU
6
5
4
3
2
1
21
7
MENU
Shown with Recommended Settings
Shown with Recommended Settings
