Appendix B: Lua extensions
70 GPIO functions
GPIO mapping table
The following table shows the mapping of GPIO pins of the TCU:
Block Pin type I/O pin
X8 PIN 1 Input/output/adc 1
X10 PIN 1 Input/output/adc 2
X12 PIN 1 Input/output/adc 3
X11 PIN 1 Input/output/adc 4
X9 PIN 1 Input/output/adc 5
X7 PIN 1 Input/output/adc 6
X14 PIN 1 Input/output 7
X8 PIN 2 Input 8
X10 PIN 2 Input 9
X12 PIN 2 Input 10
X11 PIN 2 Input 11
X9 PIN 2 Input 12
X7 PIN 2 Input 13
X14 PIN 2 Input 14
